您可以在 OpenAI 平台 文档中找到有关 OpenAI 最新模型、其成本、上下文窗口和支持的输入类型的信息。
集成详情
模型功能
工具调用 结构化输出 图像输入 音频输入 视频输入 令牌级流式传输 原生异步 令牌使用量 对数概率 ✅ ✅ ✅ ✅ ❌ ✅ ✅ ✅ ✅
要访问 OpenAI 模型,您需要安装 langchain-openai 集成包并获取 OpenAI 平台 API 密钥。
pip install -U langchain-openai
前往 OpenAI 平台 注册并生成 API 密钥。完成后,在您的环境中设置 OPENAI_API_KEY 环境变量:
import getpass
import os
if not os . environ . get ( "OPENAI_API_KEY" ):
os . environ [ " OPENAI_API_KEY " ] = getpass . getpass ( "Enter your OpenAI API key: " )
如果您想获得模型调用的自动跟踪,也可以设置您的 LangSmith API 密钥:
os . environ [ " LANGSMITH_API_KEY " ] = getpass . getpass ( "Enter your LangSmith API key: " )
os . environ [ " LANGSMITH_TRACING " ] = "true"
实例化
现在我们可以实例化模型对象并生成响应:
from langchain_openai import ChatOpenAI
llm = ChatOpenAI (
model = "gpt-5-nano" ,
# stream_usage=True,
# temperature=None,
# max_tokens=None,
# timeout=None,
# reasoning_effort="low",
# max_retries=2,
# api_key="...", # 如果您希望直接传递 api key
# base_url="...",
# organization="...",
# 其他参数...
)
有关所有可用模型参数的完整集合,请参阅 ChatOpenAI API 参考。
令牌参数弃用 OpenAI 在 2024 年 9 月弃用了 max_tokens,转而使用 max_completion_tokens。虽然 max_tokens 仍然支持向后兼容,但它在内部会自动转换为 max_completion_tokens。
messages = [
(
"system" ,
"You are a helpful assistant that translates English to French. Translate the user sentence." ,
),
( "human" , "I love programming." ),
]
ai_msg = llm . invoke ( messages )
ai_msg
AIMessage(content="J'adore la programmation.", additional_kwargs={'refusal': None}, response_metadata={'token_usage': {'completion_tokens': 5, 'prompt_tokens': 31, 'total_tokens': 36}, 'model_name': 'gpt-4o-2024-05-13', 'system_fingerprint': 'fp_3aa7262c27', 'finish_reason': 'stop', 'logprobs': None}, id='run-63219b22-03e3-4561-8cc4-78b7c7c3a3ca-0', usage_metadata={'input_tokens': 31, 'output_tokens': 5, 'total_tokens': 36})
J'adore la programmation.
流式传输使用量元数据
OpenAI 的 Chat Completions API 默认不流式传输令牌使用量统计信息(参见 OpenAI API 参考中的流式选项 )。
要在使用 ChatOpenAI 或 AzureChatOpenAI 进行流式传输时恢复令牌计数,请将 stream_usage=True 设置为初始化参数或在调用时设置:
from langchain_openai import ChatOpenAI
llm = ChatOpenAI ( model = "gpt-5.4-mini" , stream_usage = True )
与 Azure OpenAI 一起使用
Azure OpenAI v1 API 支持 从 langchain-openai>=1.0.1 开始,ChatOpenAI 可以直接与 Azure OpenAI 端点一起使用新的 v1 API 。这提供了一种统一的方式来使用 OpenAI 模型,无论它们托管在 OpenAI 还是 Azure 上。 对于传统的特定于 Azure 的实现,请继续使用 AzureChatOpenAI 。
使用 API 密钥与 Azure OpenAI v1 API
要将 ChatOpenAI 与 Azure OpenAI 一起使用,请将 base_url 设置为您的 Azure 端点,并附加 /openai/v1/: from langchain_openai import ChatOpenAI
llm = ChatOpenAI (
model = "gpt-5-mini" , # 您的 Azure 部署名称
base_url = "https://{your-resource-name}.openai.azure.com/openai/v1/" ,
api_key = "your-azure-api-key"
)
response = llm . invoke ( "Hello, how are you?" )
print ( response . content )
使用 Microsoft Entra ID 与 Azure OpenAI
v1 API 增加了对 Microsoft Entra ID (前身为 Azure AD)身份验证的原生支持,并支持自动令牌刷新。将令牌提供程序可调用对象传递给 api_key 参数: from azure . identity import DefaultAzureCredential , get_bearer_token_provider
from langchain_openai import ChatOpenAI
# 创建一个处理自动刷新的令牌提供程序
token_provider = get_bearer_token_provider (
DefaultAzureCredential (),
"https://cognitiveservices.azure.com/.default"
)
llm = ChatOpenAI (
model = "gpt-5-mini" , # 您的 Azure 部署名称
base_url = "https://{your-resource-name}.openai.azure.com/openai/v1/" ,
api_key = token_provider # 处理令牌刷新的可调用对象
)
# 正常使用模型
messages = [
( "system" , "You are a helpful assistant." ),
( "human" , "Translate 'I love programming' to French." )
]
response = llm . invoke ( messages )
print ( response . content )
令牌提供程序是一个可调用对象,它会自动获取和刷新身份验证令牌,无需手动管理令牌过期。 安装要求 要使用 Microsoft Entra ID 身份验证,请安装 Azure Identity 库: pip install azure-identity
您也可以在使用异步函数时将令牌提供程序可调用对象传递给 api_key 参数。您必须从 azure.identity.aio 导入 DefaultAzureCredential: from azure . identity . aio import DefaultAzureCredential
from langchain_openai import ChatOpenAI
credential = DefaultAzureCredential ()
llm_async = ChatOpenAI (
model = "gpt-5-nano" ,
api_key = credential
)
# 使用异步可调用对象时使用异步方法
response = await llm_async . ainvoke ( "Hello!" )
当使用异步可调用对象作为 API 密钥时,您必须使用异步方法(ainvoke、astream 等)。同步方法将引发错误。
工具调用
OpenAI 有一个工具调用 (我们在此处将“工具调用”和“函数调用”互换使用)API,允许您描述工具及其参数,并让模型返回一个 JSON 对象,其中包含要调用的工具和该工具的输入。工具调用对于构建使用工具的链和代理,以及更普遍地从模型获取结构化输出非常有用。
绑定工具
通过 ChatOpenAI.bind_tools,我们可以轻松地将 Pydantic 类、字典模式、LangChain 工具甚至函数作为工具传递给模型。在底层,这些被转换为 OpenAI 工具模式,如下所示:
{
"name": "...",
"description": "...",
"parameters": {...} # JSONSchema
}
…并在每次模型调用时传递。
from pydantic import BaseModel , Field
class GetWeather ( BaseModel ):
"""获取给定位置的当前天气"""
location : str = Field ( description = "城市和州,例如 San Francisco, CA" )
llm_with_tools = llm . bind_tools ([ GetWeather ])
ai_msg = llm_with_tools . invoke (
"what is the weather like in San Francisco" ,
)
ai_msg
AIMessage(content='', additional_kwargs={'refusal': None}, response_metadata={'token_usage': {'completion_tokens': 17, 'prompt_tokens': 68, 'total_tokens': 85}, 'model_name': 'gpt-4o-2024-05-13', 'system_fingerprint': 'fp_3aa7262c27', 'finish_reason': 'tool_calls', 'logprobs': None}, id='run-1617c9b2-dda5-4120-996b-0333ed5992e2-0', tool_calls=[{'name': 'GetWeather', 'args': {'location': 'San Francisco, CA'}, 'id': 'call_o9udf3EVOWiV4Iupktpbpofk', 'type': 'tool_call'}], usage_metadata={'input_tokens': 68, 'output_tokens': 17, 'total_tokens': 85})
严格模式
需要 langchain-openai>=0.1.21
自 2024 年 8 月 6 日起,OpenAI 在调用工具时支持 strict 参数,该参数将强制模型遵守工具参数模式。了解更多 。
如果 strict=True,工具定义也将被验证,并且只接受 JSON 模式的一个子集。关键是,模式不能有可选参数(那些具有默认值的参数)。 阅读完整文档 了解支持的模式类型。
llm_with_tools = llm . bind_tools ([ GetWeather ], strict = True )
ai_msg = llm_with_tools . invoke (
"what is the weather like in San Francisco" ,
)
ai_msg
AIMessage(content='', additional_kwargs={'tool_calls': [{'id': 'call_jUqhd8wzAIzInTJl72Rla8ht', 'function': {'arguments': '{"location":"San Francisco, CA"}', 'name': 'GetWeather'}, 'type': 'function'}], 'refusal': None}, response_metadata={'token_usage': {'completion_tokens': 17, 'prompt_tokens': 68, 'total_tokens': 85}, 'model_name': 'gpt-4o-2024-05-13', 'system_fingerprint': 'fp_3aa7262c27', 'finish_reason': 'tool_calls', 'logprobs': None}, id='run-5e3356a9-132d-4623-8e73-dd5a898cf4a6-0', tool_calls=[{'name': 'GetWeather', 'args': {'location': 'San Francisco, CA'}, 'id': 'call_jUqhd8wzAIzInTJl72Rla8ht', 'type': 'tool_call'}], usage_metadata={'input_tokens': 68, 'output_tokens': 17, 'total_tokens': 85})
工具调用
请注意,AIMessage 有一个 tool_calls 属性。它包含在标准化的 ToolCall 格式中,该格式与模型提供商无关。
[{'name': 'GetWeather',
'args': {'location': 'San Francisco, CA'},
'id': 'call_jUqhd8wzAIzInTJl72Rla8ht',
'type': 'tool_call'}]
有关绑定工具和工具调用输出的更多信息,请参阅工具调用 文档。
自定义工具
需要 langchain-openai>=0.3.29
自定义工具 支持具有任意字符串输入的工具。当您预期字符串参数较长或复杂时,它们特别有用。
from langchain_openai import ChatOpenAI , custom_tool
from langchain . agents import create_agent
@custom_tool
def execute_code ( code : str ) -> str :
"""执行 python 代码。"""
return "27"
llm = ChatOpenAI ( model = "gpt-5.4" , use_responses_api = True )
agent = create_agent ( llm , [ execute_code ])
input_message = { "role" : "user" , "content" : "Use the tool to calculate 3^3." }
for step in agent . stream (
{ "messages" : [ input_message ]},
stream_mode = "values" ,
):
step [ " messages " ][ - 1 ]. pretty_print ()
================================ Human Message =================================
Use the tool to calculate 3^3.
================================== Ai Message ==================================
[{'id': 'rs_68b7336cb72081a080da70bf5e980e4e0d6082d28f91357a', 'summary': [], 'type': 'reasoning'}, {'call_id': 'call_qyKsJ4XlGRudbIJDrXVA2nQa', 'input': 'print(3**3)', 'name': 'execute_code', 'type': 'custom_tool_call', 'id': 'ctc_68b7336f718481a0b39584cd35fbaa5d0d6082d28f91357a', 'status': 'completed'}]
Tool Calls:
execute_code (call_qyKsJ4XlGRudbIJDrXVA2nQa)
Call ID: call_qyKsJ4XlGRudbIJDrXVA2nQa
Args:
__arg1: print(3**3)
================================= Tool Message =================================
Name: execute_code
[{'type': 'custom_tool_call_output', 'output': '27'}]
================================== Ai Message ==================================
[{'type': 'text', 'text': '27', 'annotations': [], 'id': 'msg_68b73371e9e081a0927f54f88f2cd7a20d6082d28f91357a'}]
OpenAI 支持为自定义工具输入指定 上下文无关文法 ,格式为 lark 或 regex。详情请参阅 OpenAI 文档 。format 参数可以传递给 @custom_tool,如下所示: from langchain_openai import ChatOpenAI , custom_tool
from langchain . agents import create_agent
grammar = """
start: expr
expr: term (SP ADD SP term)* -> add
| term
term: factor (SP MUL SP factor)* -> mul
| factor
factor: INT
SP: " "
ADD: "+"
MUL: "*"
%i mport common.INT
"""
format_ = { "type" : "grammar" , "syntax" : "lark" , "definition" : grammar }
@custom_tool ( format = format_ )
def do_math ( input_string : str ) -> str :
"""执行数学运算。"""
return "27"
llm = ChatOpenAI ( model = "gpt-5.4" , use_responses_api = True )
agent = create_agent ( llm , [ do_math ])
input_message = { "role" : "user" , "content" : "Use the tool to calculate 3^3." }
for step in agent . stream (
{ "messages" : [ input_message ]},
stream_mode = "values" ,
):
step [ " messages " ][ - 1 ]. pretty_print ()
================================ Human Message =================================
Use the tool to calculate 3^3.
================================== Ai Message ==================================
[{'id': 'rs_68b733f066a48194a41001c0cc1081760811f11b6f4bae47', 'summary': [], 'type': 'reasoning'}, {'call_id': 'call_7hTYtlTj9NgWyw8AQGqETtV9', 'input': '3 * 3 * 3', 'name': 'do_math', 'type': 'custom_tool_call', 'id': 'ctc_68b733f3a0a08194968b8338d33ad89f0811f11b6f4bae47', 'status': 'completed'}]
Tool Calls:
do_math (call_7hTYtlTj9NgWyw8AQGqETtV9)
Call ID: call_7hTYtlTj9NgWyw8AQGqETtV9
Args:
__arg1: 3 * 3 * 3
================================= Tool Message =================================
Name: do_math
[{'type': 'custom_tool_call_output', 'output': '27'}]
================================== Ai Message ==================================
[{'type': 'text', 'text': '27', 'annotations': [], 'id': 'msg_68b733f4bb008194937130796372bd0f0811f11b6f4bae47'}]
结构化输出
OpenAI 支持原生的结构化输出功能 ,保证其响应遵循给定的模式。
您可以在单个模型调用中访问此功能,也可以通过指定 LangChain 代理 的响应格式 来访问。示例如下。
使用 with_structured_output 方法生成结构化的模型响应。指定 method="json_schema" 以启用 OpenAI 的原生结构化输出功能;否则该方法默认使用函数调用。 from langchain_openai import ChatOpenAI
from pydantic import BaseModel , Field
llm = ChatOpenAI ( model = "gpt-5.4" )
class Movie ( BaseModel ):
"""一部包含详情的电影。"""
title : str = Field ( description = "电影标题" )
year : int = Field ( description = "电影发行年份" )
director : str = Field ( description = "电影导演" )
rating : float = Field ( description = "电影评分,满分10分" )
structured_llm = llm . with_structured_output ( Movie , method = "json_schema" )
response = structured_llm . invoke ( "Provide details about the movie Inception" )
response
Movie ( title = 'Inception' , year = 2010 , director = 'Christopher Nolan' , rating = 8.8 )
使用 ProviderStrategy 指定 response_format,以便在生成最终响应时启用 OpenAI 的结构化输出功能。 from langchain . agents import create_agent
from langchain . agents . structured_output import ProviderStrategy
from pydantic import BaseModel
class Weather ( BaseModel ):
temperature : float
condition : str
def weather_tool ( location : str ) -> str :
"""获取某个位置的天气。"""
return "Sunny and 75 degrees F."
agent = create_agent (
model = "openai:gpt-5.4" ,
tools = [ weather_tool ],
response_format = ProviderStrategy ( Weather ),
)
result = agent . invoke ({
"messages" : [{ "role" : "user" , "content" : "What's the weather in SF?" }]
})
result [ " structured_response " ]
Weather ( temperature = 75.0 , condition = 'Sunny' )
结合工具调用的结构化输出
OpenAI 的结构化输出 功能可以与工具调用同时使用。模型将生成工具调用或遵循所需模式的响应。示例如下:
from langchain_openai import ChatOpenAI
from pydantic import BaseModel
def get_weather ( location : str ) -> None :
"""获取某个位置的天气。"""
return "It's sunny."
class OutputSchema ( BaseModel ):
"""响应模式。"""
answer : str
justification : str
llm = ChatOpenAI ( model = "gpt-5.4" )
structured_llm = llm . bind_tools (
[ get_weather ],
response_format = OutputSchema ,
strict = True ,
)
# 响应包含工具调用:
tool_call_response = structured_llm . invoke ( "What is the weather in SF?" )
# structured_response.additional_kwargs["parsed"] 包含解析后的输出
structured_response = structured_llm . invoke (
"What weighs more, a pound of feathers or a pound of gold?"
)
Responses API
需要 langchain-openai>=0.3.9
OpenAI 支持一个 Responses API,该 API 面向构建代理 应用程序。它包含一套内置工具 ,包括网络和文件搜索。它还支持管理对话状态 ,允许您继续对话线程而无需显式传递之前的消息,以及来自推理过程 的输出。
如果使用了这些功能之一,ChatOpenAI 将路由到 Responses API。您也可以在实例化 ChatOpenAI 时指定 use_responses_api=True。
网络搜索
要触发网络搜索,请将 {"type": "web_search_preview"} 作为工具传递给模型。
您也可以将内置工具作为调用参数传递: llm . invoke ( "..." , tools = [{ "type" : "web_search_preview" }])
from langchain_openai import ChatOpenAI
llm = ChatOpenAI ( model = "gpt-5.4-mini" )
tool = { "type" : "web_search_preview" }
llm_with_tools = llm . bind_tools ([ tool ])
response = llm_with_tools . invoke ( "What was a positive news story from today?" )
请注意,响应包含结构化的内容块 ,其中包括响应文本和引用其来源的 OpenAI 注释 。输出消息还将包含来自任何工具调用的信息:
[{'type': 'server_tool_call',
'name': 'web_search',
'args': {'query': 'positive news stories today', 'type': 'search'},
'id': 'ws_68cd6f8d72e4819591dab080f4b0c340080067ad5ea8144a'},
{'type': 'server_tool_result',
'tool_call_id': 'ws_68cd6f8d72e4819591dab080f4b0c340080067ad5ea8144a',
'status': 'success'},
{'type': 'text',
'text': 'Here are some positive news stories from today...',
'annotations': [{'end_index': 410,
'start_index': 337,
'title': 'Positive News | Real Stories. Real Positive Impact',
'type': 'citation',
'url': 'https://www.positivenews.press/?utm_source=openai'},
{'end_index': 969,
'start_index': 798,
'title': "From Green Innovation to Community Triumphs: Uplifting US Stories Lighting Up September 2025 | That's Great News",
'type': 'citation',
'url': 'https://info.thatsgreatnews.com/from-green-innovation-to-community-triumphs-uplifting-us-stories-lighting-up-september-2025/?utm_source=openai'},
'id': 'msg_68cd6f8e8d448195a807b89f483a1277080067ad5ea8144a'}]
您可以使用 response.text 仅将响应的文本内容作为字符串恢复。例如,要流式传输响应文本: for token in llm_with_tools . stream ( "..." ):
print ( token . text , end = "|" )
有关更多详细信息,请参阅流式传输指南 。
图像生成
需要 langchain-openai>=0.3.19
要触发图像生成,请将 {"type": "image_generation"} 作为工具传递给模型。
您也可以将内置工具作为调用参数传递: llm . invoke ( "..." , tools = [{ "type" : "image_generation" }])
from langchain_openai import ChatOpenAI
llm = ChatOpenAI ( model = "gpt-5.4-mini" )
tool = { "type" : "image_generation" , "quality" : "low" }
llm_with_tools = llm . bind_tools ([ tool ])
ai_message = llm_with_tools . invoke (
"Draw a picture of a cute fuzzy cat with an umbrella"
)
import base64
from IPython . display import Image
image = next (
item for item in ai_message . content_blocks if item [ " type " ] == "image"
)
Image ( base64 . b64decode ( image [ " base64 " ]), width = 200 )
文件搜索
要触发文件搜索,请将文件搜索工具 作为工具传递给模型。您需要填充一个 OpenAI 管理的向量存储,并在工具定义中包含向量存储 ID。详情请参阅 OpenAI 文档 。
from langchain_openai import ChatOpenAI
llm = ChatOpenAI (
model = "gpt-5.4-mini" ,
include = [ "file_search_call.results" ], # 可选地包含搜索结果
)
openai_vector_store_ids = [
"vs_..." , # 您的 ID 在这里
]
tool = {
"type" : "file_search" ,
"vector_store_ids" : openai_vector_store_ids ,
}
llm_with_tools = llm . bind_tools ([ tool ])
response = llm_with_tools . invoke ( "What is deep research by OpenAI?" )
print ( response . text )
Deep Research by OpenAI is...
与网络搜索 一样,响应将包含带有引用的内容块:
[ block [ " type " ] for block in response . content_blocks ]
[ 'server_tool_call' , 'server_tool_result' , 'text' ]
text_block = next ( block for block in response . content_blocks if block [ " type " ] == "text" )
text_block [ " annotations " ][: 2 ]
[{'type': 'citation',
'title': 'deep_research_blog.pdf',
'extras': {'file_id': 'file-3UzgX7jcC8Dt9ZAFzywg5k', 'index': 2712}},
{'type': 'citation',
'title': 'deep_research_blog.pdf',
'extras': {'file_id': 'file-3UzgX7jcC8Dt9ZAFzywg5k', 'index': 2712}}]
它还将包含来自内置工具调用的信息:
response . content_blocks [ 0 ]
{'type': 'server_tool_call',
'name': 'file_search',
'id': 'fs_68cd704c191c81959281b3b2ec6b139908f8f7fb31b1123c',
'args': {'queries': ['deep research by OpenAI']}}
工具搜索
需要 langchain-openai>=1.1.11
OpenAI 支持工具搜索 功能,允许模型根据需要搜索并将工具加载到其上下文中。OpenAI 会将检索到的工具定义注入到活动上下文的末尾,以保留其缓存 。
要启用工具搜索,请使用 @tool(extras={"defer_loading": True}) 标记工具,并将 OpenAI 的搜索工具添加到可用工具中。示例如下。
OpenAI 可以搜索可用工具,并在同一个响应中返回加载的工具(如果合适,还包括工具调用): @tool ( extras = { "defer_loading" : True })
def get_weather ( location : str ) -> str :
"""获取某个位置的当前天气。"""
return f "The weather in { location } is sunny and 72°F"
@tool ( extras = { "defer_loading" : True })
def get_recipe ( query : str ) -> None :
"""获取鸡汤食谱。"""
model = ChatOpenAI ( model = "gpt-5.4" , use_responses_api = True )
agent = create_agent (
model = model ,
tools = [
get_weather ,
get_recipe ,
{ "type" : "tool_search" }
],
)
input_message = { "role" : "user" , "content" : "What's the weather in San Francisco?" }
result = agent . invoke ({ "messages" : [ input_message ]})
for message in result [ " messages " ]:
message . pretty_print ()
================================ Human Message =================================
What's the weather in San Francisco?
================================== Ai Message ==================================
[
{
"id": "tsc_0667642bae2ae6c70069ad6cb31f0c819c838b18b0e1cf1279",
"arguments": {
"paths": [
"get_weather"
]
},
"execution": "server",
"status": "completed",
"type": "tool_search_call"
},
{
"id": "tso_0667642bae2ae6c70069ad6cb339dc819c9bbc05cb432f347e",
"execution": "server",
"status": "completed",
"tools": [
{
"name": "get_weather",
"parameters": {
"properties": {
"location": {
"type": "string"
}
},
"required": [
"location"
],
"type": "object",
"additionalProperties": false
},
"strict": true,
"type": "function",
"defer_loading": true,
"description": "Get the current weather for a location."
}
],
"type": "tool_search_output"
},
{
"arguments": "{\"location\":\"San Francisco\"}",
"call_id": "call_nwy9NDI24fTe8qESIRqZGtYm",
"name": "get_weather",
"type": "function_call",
"id": "fc_0667642bae2ae6c70069ad6cb37adc819cbc55cde85e111e32",
"namespace": "get_weather",
"status": "completed"
}
]
Tool Calls:
get_weather (call_nwy9NDI24fTe8qESIRqZGtYm)
Call ID: call_nwy9NDI24fTe8qESIRqZGtYm
Args:
location: San Francisco
================================= Tool Message =================================
Name: get_weather
The weather in San Francisco is sunny and 72°F
================================== Ai Message ==================================
[
{
"type": "text",
"text": "It\u2019s currently sunny and 72\u00b0F in San Francisco.",
"annotations": [],
"id": "msg_0667642bae2ae6c70069ad6cb4829c819c8e26bc7ccc68dcd7"
}
]
要完全控制底层的工具搜索过程,您可以在搜索工具定义中指定 "execution": "client"。如果模型选择搜索工具,它将在响应中包含一个 tool_search_call 块。然后您可以提供一个包含工具定义的 tool_search_output 块。 以下示例展示了如何使用自定义中间件 来编排此过程。该示例实现了一个定义搜索逻辑的可调用对象。中间件包括:
一个 after_model 钩子,用于检查 tool_search_call 块并调用我们的可调用对象
一个 wrap_tool_call 钩子,用于运行时工具注册
@tool
def get_weather ( location : str ) -> str :
"""获取某个位置的当前天气。"""
return f "The weather in { location } is sunny and 72°F"
# 实现一个返回工具定义的可调用对象
def search_tools ( goal : str ) -> list [ dict ]:
"""搜索可用工具以帮助回答问题。"""
# 这里是任意逻辑
return [
{
"type" : "function" ,
"defer_loading" : True ,
** convert_to_openai_tool ( get_weather )[ "function" ],
}
]
tool_search_schema = convert_to_openai_tool ( search_tools , strict = True )
tool_search_config : dict = {
"type" : "tool_search" ,
"execution" : "client" ,
"description" : tool_search_schema [ " function " ][ "description" ],
"parameters" : tool_search_schema [ " function " ][ "parameters" ],
}
# 实现中间件以调用可调用对象并注册工具。
class ClientToolSearchMiddleware ( AgentMiddleware ):
@hook_config ( can_jump_to = [ "model" ])
def after_model ( self , state : AgentState , runtime : Any ) -> dict [ str , Any ] | None :
last_message = state [ " messages " ][ - 1 ]
if not isinstance ( last_message , AIMessage ):
return None
for block in last_message . content :
if isinstance ( block , dict ) and block . get ( "type" ) == "tool_search_call" :
call_id = block . get ( "call_id" )
args = block . get ( "arguments" , {})
goal = args . get ( "goal" , "" ) if isinstance ( args , dict ) else ""
loaded_tools = search_tools ( goal )
tool_search_output = {
"type" : "tool_search_output" ,
"execution" : "client" ,
"call_id" : call_id ,
"status" : "completed" ,
"tools" : loaded_tools ,
}
return {
"messages" : [ HumanMessage ( content = [ tool_search_output ])],
"jump_to" : "model" ,
}
return None
def wrap_tool_call (
self ,
request : ToolCallRequest ,
handler : Any ,
) -> Any :
if request . tool_call [ " name " ] == "get_weather" :
return handler ( request . override ( tool = get_weather ))
return handler ( request )
llm = ChatOpenAI ( model = "gpt-5.4" , use_responses_api = True )
agent = create_agent (
model = llm ,
tools = [ tool_search_config ],
middleware = [ ClientToolSearchMiddleware ()],
)
result = agent . invoke (
{ "messages" : [ HumanMessage ( "What's the weather in San Francisco?" )]}
)
for message in result [ " messages " ]:
message . pretty_print ()
================================ Human Message =================================
What's the weather in San Francisco?
================================== Ai Message ==================================
[
{
"id": "tsc_0311ca847e392d540069acdd40394c8196a99345e2992eb657",
"arguments": {
"goal": "Find available tool(s) or weather capability to get current weather for San Francisco."
},
"call_id": "call_EcvKsh3r9IamaBW4Zz9r7RiK",
"execution": "client",
"status": "completed",
"type": "tool_search_call"
}
]
================================ Human Message =================================
[
{
"type": "tool_search_output",
"execution": "client",
"call_id": "call_EcvKsh3r9IamaBW4Zz9r7RiK",
"status": "completed",
"tools": [
{
"type": "function",
"defer_loading": true,
"name": "get_weather",
"description": "Get the current weather for a location.",
"parameters": {
"properties": {
"location": {
"type": "string"
}
},
"required": [
"location"
],
"type": "object"
}
}
]
}
]
================================== Ai Message ==================================
[
{
"arguments": "{\"location\":\"San Francisco\"}",
"call_id": "call_wH09dZpqDoVtpeu7uBdvY91l",
"name": "get_weather",
"type": "function_call",
"id": "fc_0311ca847e392d540069acdd41502881968b29d96840633746",
"namespace": "get_weather",
"status": "completed"
}
]
Tool Calls:
get_weather (call_wH09dZpqDoVtpeu7uBdvY91l)
Call ID: call_wH09dZpqDoVtpeu7uBdvY91l
Args:
location: San Francisco
================================= Tool Message =================================
Name: get_weather
The weather in San Francisco is sunny and 72°F
================================== Ai Message ==================================
[
{
"type": "text",
"text": "San Francisco is sunny and 72\u00b0F.",
"annotations": [],
"id": "msg_0311ca847e392d540069acdd420b648196a603306f5546fabd"
}
]
计算机使用
ChatOpenAI 支持 "computer-use-preview" 模型,这是一个用于内置计算机使用工具的专用模型。要启用,请像传递其他工具一样传递计算机使用工具 。
目前,计算机使用的工具输出存在于消息的 content 字段中。要回复计算机使用工具调用,请构造一个 ToolMessage ,并在其 additional_kwargs 中包含 {"type": "computer_call_output"}。消息的内容将是一个截图。下面我们演示一个简单的示例。
首先,加载两个截图:
import base64
def load_png_as_base64 ( file_path ):
with open ( file_path , "rb" ) as image_file :
encoded_string = base64 . b64encode ( image_file . read ())
return encoded_string . decode ( "utf-8" )
screenshot_1_base64 = load_png_as_base64 (
"/path/to/screenshot_1.png"
) # 可能是应用程序的截图
screenshot_2_base64 = load_png_as_base64 (
"/path/to/screenshot_2.png"
) # 可能是桌面的截图
from langchain_openai import ChatOpenAI
# 初始化模型
llm = ChatOpenAI ( model = "computer-use-preview" , truncation = "auto" )
# 绑定计算机使用工具
tool = {
"type" : "computer_use_preview" ,
"display_width" : 1024 ,
"display_height" : 768 ,
"environment" : "browser" ,
}
llm_with_tools = llm . bind_tools ([ tool ])
# 构造输入消息
input_message = {
"role" : "user" ,
"content" : [
{
"type" : "text" ,
"text" : (
"Click the red X to close and reveal my Desktop. "
"Proceed, no confirmation needed."
),
},
{
"type" : "input_image" ,
},
],
}
# 调用模型
response = llm_with_tools . invoke (
[ input_message ],
reasoning = {
"generate_summary" : "concise" ,
},
)
响应将在其 content 中包含对计算机使用工具的调用:
[{'id': 'rs_685da051742c81a1bb35ce46a9f3f53406b50b8696b0f590',
'summary': [{'text': "Clicking red 'X' to show desktop",
'type': 'summary_text'}],
'type': 'reasoning'},
{'id': 'cu_685da054302481a1b2cc43b56e0b381706b50b8696b0f590',
'action': {'button': 'left', 'type': 'click', 'x': 14, 'y': 38},
'call_id': 'call_zmQerFBh4PbBE8mQoQHkfkwy',
'pending_safety_checks': [],
'status': 'completed',
'type': 'computer_call'}]
接下来,我们构造一个具有以下属性的 ToolMessage :
它有一个 tool_call_id,与计算机调用中的 call_id 匹配。
它的 additional_kwargs 中包含 {"type": "computer_call_output"}。
它的内容要么是 image_url,要么是 input_image 输出块(格式参见 OpenAI 文档 )。
from langchain . messages import ToolMessage
tool_call_id = next (
item [ " call_id " ] for item in response . content if item [ " type " ] == "computer_call"
)
tool_message = ToolMessage (
content = [
{
"type" : "input_image" ,
}
],
tool_call_id = tool_call_id ,
additional_kwargs = { "type" : "computer_call_output" },
)
我们现在可以使用消息历史再次调用模型:
messages = [
input_message ,
response ,
tool_message ,
]
response_2 = llm_with_tools . invoke (
messages ,
reasoning = {
"generate_summary" : "concise" ,
},
)
'VS Code has been closed, and the desktop is now visible.'
我们也可以使用 previous_response_id 代替传递整个序列:
previous_response_id = response . response_metadata [ " id " ]
response_2 = llm_with_tools . invoke (
[ tool_message ],
previous_response_id = previous_response_id ,
reasoning = {
"generate_summary" : "concise" ,
},
)
'The VS Code window is closed, and the desktop is now visible. Let me know if you need any further assistance.'
代码解释器
OpenAI 实现了一个代码解释器 工具,以支持代码的沙盒生成和执行。
from langchain_openai import ChatOpenAI
llm = ChatOpenAI (
model = "gpt-5.4-mini" ,
include = [ "code_interpreter_call.outputs" ], # 可选地包含输出
)
llm_with_tools = llm . bind_tools (
[
{
"type" : "code_interpreter" ,
# 创建一个新容器
"container" : { "type" : "auto" },
}
]
)
response = llm_with_tools . invoke (
"Write and run code to answer the question: what is 3^3?"
)
请注意,上述命令创建了一个新容器。我们也可以指定一个现有的容器 ID:
code_interpreter_calls = [
item for item in response . content if item [ " type " ] == "code_interpreter_call"
]
assert len ( code_interpreter_calls ) == 1
container_id = code_interpreter_calls [ 0 ][ "extras" ][ "container_id" ]
llm_with_tools = llm . bind_tools (
[
{
"type" : "code_interpreter" ,
# 使用现有容器
"container" : container_id ,
}
]
)
远程 MCP
OpenAI 实现了一个远程 MCP 工具,允许模型生成对 MCP 服务器的调用。
from langchain_openai import ChatOpenAI
llm = ChatOpenAI ( model = "gpt-5.4-mini" )
llm_with_tools = llm . bind_tools (
[
{
"type" : "mcp" ,
"server_label" : "deepwiki" ,
"server_url" : "https://mcp.deepwiki.com/mcp" ,
"require_approval" : "never" ,
}
]
)
response = llm_with_tools . invoke (
"What transport protocols does the 2025-03-26 version of the MCP "
"spec (modelcontextprotocol/modelcontextprotocol) support?"
)
OpenAI 有时会在与远程 MCP 服务器共享数据之前请求批准。 在上面的命令中,我们指示模型永远不需要批准。我们也可以配置模型始终请求批准,或者始终为特定工具请求批准: llm_with_tools = llm . bind_tools (
[
{
"type" : "mcp" ,
"server_label" : "deepwiki" ,
"server_url" : "https://mcp.deepwiki.com/mcp" ,
"require_approval" : {
"always" : {
"tool_names" : [ "read_wiki_structure" ]
}
}
}
]
)
response = llm_with_tools . invoke (
"What transport protocols does the 2025-03-26 version of the MCP "
"spec (modelcontextprotocol/modelcontextprotocol) support?"
)
响应可能随后包含类型为 "mcp_approval_request" 的块。 要提交审批请求的批准,请将其构造为输入消息中的内容块: approval_message = {
"role" : "user" ,
"content" : [
{
"type" : "mcp_approval_response" ,
"approve" : True ,
"approval_request_id" : block [ " id " ],
}
for block in response . content
if block [ " type " ] == "mcp_approval_request"
]
}
next_response = llm_with_tools . invoke (
[ approval_message ],
# 继续现有线程
previous_response_id = response . response_metadata [ " id " ]
)
管理对话状态
Responses API 支持管理对话状态 。
手动管理状态
您可以像使用其他聊天模型一样,手动或使用 LangGraph 管理状态:
from langchain_openai import ChatOpenAI
llm = ChatOpenAI ( model = "gpt-5.4-mini" , use_responses_api = True )
first_query = "Hi, I'm Bob."
messages = [{ "role" : "user" , "content" : first_query }]
response = llm . invoke ( messages )
print ( response . text )
Hi Bob! Nice to meet you. How can I assist you today?
second_query = "What is my name?"
messages . extend (
[
response ,
{ "role" : "user" , "content" : second_query },
]
)
second_response = llm . invoke ( messages )
print ( second_response . text )
You mentioned that your name is Bob. How can I assist you further, Bob?
传递 previous_response_id
使用 Responses API 时,LangChain 消息将在其元数据中包含一个 "id" 字段。将此 ID 传递给后续调用将继续对话。请注意,从计费角度来看,这与手动传递消息等效 。
second_response = llm . invoke (
"What is my name?" ,
previous_response_id = response . id ,
)
print ( second_response . text )
Your name is Bob. How can I help you today, Bob?
ChatOpenAI 也可以使用消息序列中的最后一个响应自动指定 previous_response_id:
from langchain_openai import ChatOpenAI
llm = ChatOpenAI (
model = "gpt-5.4-mini" ,
use_previous_response_id = True ,
)
如果我们设置 use_previous_response_id=True,输入消息(直到最近的响应)将从请求负载中丢弃,并且 previous_response_id 将使用最近响应的 ID 设置。
也就是说,
llm . invoke (
[
HumanMessage ( "Hello" ),
AIMessage ( "Hi there!" , id = "resp_123" ),
HumanMessage ( "How are you?" ),
]
)
…等同于:
llm . invoke ([ HumanMessage ( "How are you?" )], previous_response_id = "resp_123" )
上下文管理
Responses API 支持自动的服务器端上下文压缩 。当对话达到令牌阈值时,这会减少对话大小,从而支持长时间运行的交互:
from langchain_openai import ChatOpenAI
model = ChatOpenAI (
model = "gpt-5.4" ,
context_management = [
{ "type" : "compaction" , "compact_threshold" : 100_000 }
],
)
启用后,AIMessage 响应可能在内容中包含类型为 "compaction" 的块。这些应保留在对话历史中,并可以以通常的方式 附加到消息序列中。可以保留最近 compaction 项之前的消息,也可以丢弃它们以提高延迟。
推理输出
一些 OpenAI 模型将生成单独的文本内容来说明其推理过程。详情请参阅 OpenAI 的推理文档 。
OpenAI 可以返回模型推理的摘要(尽管它不暴露原始推理令牌)。要配置 ChatOpenAI 返回此摘要,请指定 reasoning 参数。如果设置了此参数,ChatOpenAI 将自动路由到 Responses API。
from langchain_openai import ChatOpenAI
reasoning = {
"effort" : "medium" , # 'low', 'medium', 或 'high'
"summary" : "auto" , # 'detailed', 'auto', 或 None
}
llm = ChatOpenAI ( model = "gpt-5-nano" , reasoning = reasoning )
response = llm . invoke ( "What is 3^3?" )
# 输出
response . text
# 推理
for block in response . content_blocks :
if block [ " type " ] == "reasoning" :
print ( block [ " reasoning " ])
**Calculating the power of three**
The user is asking about 3 raised to the power of 3. That's a pretty simple calculation! I know that 3^3 equals 27, so I can say, "3 to the power of 3 equals 27." I might also include a quick explanation that it's 3 multiplied by itself three times: 3 × 3 × 3 = 27. So, the answer is definitely 27.
故障排除:推理模型的空响应 如果您从 gpt-5-nano 等推理模型获得空响应,这可能是由于令牌限制过于严格。模型使用令牌进行内部推理,可能没有剩余令牌用于最终输出。 确保 max_tokens 设置为 None 或增加令牌限制,以允许足够的令牌用于推理和输出生成。
您可以通过传递相应的 modelName 参数来调用微调的 OpenAI 模型。
这通常采用 ft:{OPENAI_MODEL_NAME}:{ORG_NAME}::{MODEL_ID} 的形式。例如:
fine_tuned_model = ChatOpenAI (
temperature = 0 , model_name = "ft:gpt-3.5-turbo-0613:langchain::7qTVM5AR"
)
fine_tuned_model . invoke ( messages )
AIMessage(content="J'adore la programmation.", additional_kwargs={'refusal': None}, response_metadata={'token_usage': {'completion_tokens': 8, 'prompt_tokens': 31, 'total_tokens': 39}, 'model_name': 'ft:gpt-3.5-turbo-0613:langchain::7qTVM5AR', 'system_fingerprint': None, 'finish_reason': 'stop', 'logprobs': None}, id='run-0f39b30e-c56e-4f3b-af99-5c948c984146-0', usage_metadata={'input_tokens': 31, 'output_tokens': 8, 'total_tokens': 39})
多模态输入(图像、PDF、音频)
OpenAI 有支持多模态输入的模型。您可以将图像、PDF 或音频传递给这些模型。有关如何在 LangChain 中执行此操作的更多信息,请参阅多模态输入 文档。
您可以在 OpenAI 文档 中查看支持不同模态的模型列表。
对于所有模态,LangChain 都支持其跨提供商标准以及 OpenAI 的原生内容块格式。
要将多模态数据传递给 ChatOpenAI ,请创建一个包含数据的内容块 并将其合并到消息中,例如,如下所示:
message = {
"role" : "user" ,
"content" : [
{
"type" : "text" ,
# 根据需要更新提示
"text" : "Describe the (image / PDF / audio...)" ,
},
content_block ,
],
}
内容块示例如下。
请参阅多模态消息操作指南 中的示例。 # LangChain 格式
content_block = {
"type" : "image" ,
"url" : url_string ,
}
# OpenAI Chat Completions 格式
content_block = {
"type" : "image_url" ,
"image_url" : { "url" : url_string },
}
# LangChain 格式
content_block = {
"type" : "image" ,
"base64" : base64_string ,
"mime_type" : "image/jpeg" ,
}
# OpenAI Chat Completions 格式
content_block = {
"type" : "image_url" ,
"image_url" : {
},
}
注意:OpenAI 要求为 PDF 输入指定文件名。使用 LangChain 的格式时,请包含 filename 键。 阅读更多关于 OpenAI 多模态消息文件名 的信息。 请参阅 PDF 文档操作指南 中的示例。 # LangChain 格式
content_block = {
"type" : "file" ,
"base64" : base64_string ,
"mime_type" : "application/pdf" ,
"filename" : "my-file.pdf" ,
}
# OpenAI Chat Completions 格式
content_block = {
"type" : "file" ,
"file" : {
"filename" : "my-file.pdf" ,
"file_data" : f "data:application/pdf;base64, { base64_string } " ,
}
}
请参阅支持的模型 ,例如 "gpt-4o-audio-preview"。 请参阅音频操作指南 中的示例。 # LangChain 格式
content_block = {
"type" : "audio" ,
"mime_type" : "audio/wav" , # 或适当的 mime 类型
"base64" : base64_string ,
}
# OpenAI Chat Completions 格式
content_block = {
"type" : "input_audio" ,
"input_audio" : { "data" : base64_string , "format" : "wav" },
}
预测输出
需要 langchain-openai>=0.2.6
一些 OpenAI 模型(例如其 gpt-4o 和 gpt-4o-mini 系列)支持预测输出 ,允许您提前传递 LLM 预期输出的已知部分以减少延迟。这对于编辑文本或代码等情况很有用,因为模型输出中只有一小部分会发生变化。
以下是一个示例:
code = """
/// <summary>
/// Represents a user with a first name, last name, and username.
/// </summary>
public class User
{
/// <summary>
/// Gets or sets the user's first name.
/// </summary>
public string FirstName { get; set; }
/// <summary>
/// Gets or sets the user's last name.
/// </summary>
public string LastName { get; set; }
/// <summary>
/// Gets or sets the user's username.
/// </summary>
public string Username { get; set; }
}
"""
llm = ChatOpenAI ( model = "gpt-5.4" )
query = (
"Replace the Username property with an Email property. "
"Respond only with code, and with no markdown formatting."
)
response = llm . invoke (
[{ "role" : "user" , "content" : query }, { "role" : "user" , "content" : code }],
prediction = { "type" : "content" , "content" : code },
)
print ( response . content )
print ( response . response_metadata )
/// < summary >
/// Represents a user with a first name , last name , and email .
/// </ summary >
public class User
{
/// < summary >
/// Gets or sets the user 's first name.
/// </ summary >
public string FirstName { get; set ; }
/// < summary >
/// Gets or sets the user 's last name.
/// </ summary >
public string LastName { get; set ; }
/// < summary >
/// Gets or sets the user 's email.
/// </ summary >
public string Email { get; set ; }
}
{ 'token_usage' : { 'completion_tokens' : 226 , 'prompt_tokens' : 166 , 'total_tokens' : 392 , 'completion_tokens_details' : { 'accepted_prediction_tokens' : 49 , 'audio_tokens' : None , 'reasoning_tokens' : 0 , 'rejected_prediction_tokens' : 107 }, 'prompt_tokens_details' : { 'audio_tokens' : None , 'cached_tokens' : 0 }}, 'model_name' : 'gpt-4o-2024-08-06' , 'system_fingerprint' : 'fp_45cf54deae' , 'finish_reason' : 'stop' , 'logprobs' : None }
预测作为额外令牌计费,可能会增加您的使用量和成本,以换取降低的延迟。
音频生成(预览)
需要 langchain-openai>=0.2.3
OpenAI 有一个新的音频生成功能 ,允许您使用 gpt-4o-audio-preview 模型进行音频输入和输出。
from langchain_openai import ChatOpenAI
llm = ChatOpenAI (
model = "gpt-4o-audio-preview" ,
temperature = 0 ,
model_kwargs = {
"modalities" : [ "text" , "audio" ],
"audio" : { "voice" : "alloy" , "format" : "wav" },
},
)
output_message = llm . invoke (
[
( "human" , "Are you made by OpenAI? Just answer yes or no" ),
]
)
output_message.additional_kwargs['audio'] 将包含一个类似以下的字典
{
'data' : '<audio data b64-encoded' ,
'expires_at' : 1729268602 ,
'id' : 'audio_67127d6a44348190af62c1530ef0955a' ,
'transcript' : 'Yes.'
}
…格式将是 model_kwargs['audio']['format'] 中传递的内容。
我们也可以在 openai expires_at 到达之前,将此包含音频数据的消息作为消息历史的一部分传递回模型。
输出音频存储在 AIMessage.additional_kwargs 的 audio 键下,但输入内容块在 HumanMessage.content 列表中使用 input_audio 类型和键进行类型化。 有关更多信息,请参阅 OpenAI 的音频文档 。
history = [
( "human" , "Are you made by OpenAI? Just answer yes or no" ),
output_message ,
( "human" , "And what is your name? Just give your name." ),
]
second_output_message = llm . invoke ( history )
提示缓存
OpenAI 的提示缓存 功能会自动缓存超过 1024 个令牌的提示,以降低成本并提高响应时间。此功能对所有最新模型(gpt-4o 及更新版本)启用。
手动缓存
您可以使用 prompt_cache_key 参数来影响 OpenAI 的缓存并优化缓存命中率:
from langchain_openai import ChatOpenAI
llm = ChatOpenAI ( model = "gpt-5.4" )
# 对重复提示使用缓存键
messages = [
{ "role" : "system" , "content" : "You are a helpful assistant that translates English to French." },
{ "role" : "user" , "content" : "I love programming." },
]
response = llm . invoke (
messages ,
prompt_cache_key = "translation-assistant-v1"
)
# 检查缓存使用情况
cache_read_tokens = response . usage_metadata . input_token_details . cache_read
print ( f "Cached tokens used: { cache_read_tokens } " )
缓存键策略
您可以根据应用程序的需要使用不同的缓存键策略:
# 用于一致提示模板的静态缓存键
customer_response = llm . invoke (
messages ,
prompt_cache_key = "customer-support-v1"
)
support_response = llm . invoke (
messages ,
prompt_cache_key = "internal-support-v1"
)
# 基于上下文的动态缓存键
user_type = "premium"
cache_key = f "assistant- { user_type } -v1"
response = llm . invoke ( messages , prompt_cache_key = cache_key )
模型级缓存
您也可以使用 model_kwargs 在模型级别设置默认缓存键:
llm = ChatOpenAI (
model = "gpt-5.4-mini" ,
model_kwargs = { "prompt_cache_key" : "default-cache-v1" }
)
# 使用默认缓存键
response1 = llm . invoke ( messages )
# 使用特定缓存键覆盖
response2 = llm . invoke ( messages , prompt_cache_key = "override-cache-v1" )
弹性处理
OpenAI 提供多种服务层级 。“弹性”层级提供更便宜的请求定价,但代价是响应可能需要更长时间,并且资源可能并不总是可用。此方法最适合非关键任务,包括模型测试、数据增强或可以异步运行的任务。
要使用它,请使用 service_tier="flex" 初始化模型:
llm = ChatOpenAI ( model = "o4-mini" , service_tier = "flex" )
请注意,这是一个仅对部分模型可用的 beta 功能。详情请参阅 OpenAI 文档 。
API 参考
有关所有功能和配置选项的详细文档,请参阅 ChatOpenAI API 参考。
将这些文档 通过 MCP 连接到 Claude、VSCode 等,以获取实时答案。
